MCP2515 CAN Bus Module with TJA1050 Receiver

The MCP2515 CAN Bus Interface Module is designed to seamlessly implement the CAN 2.0B protocol, facilitating robust microcontroller communication networks. Equipped with the TJA1050 line driver, it ensures efficient signal transmission along the CAN bus wires.

At the heart of the module lies the MCP2515 CAN Controller IC, responsible for orchestrating the intricate logic behind CAN bus management. Facilitating seamless integration with associated MCUs, it features an SPI interface for streamlined connectivity.

Complementing the controller is the TJA1050 CAN Transceiver chip, adept at converting digital data into the requisite differential signalling essential for CAN bus communication.

Renowned for its extensive range, moderate communication speeds, and unwavering reliability, Controller Area Network, or CAN-BUS, stands as a staple in industrial settings. It finds widespread application in modern machine tools and serves as a cornerstone in automotive diagnostic systems.

Features

• Supports CAN V2.0B
• Communication rate: Up to 1Mb/S
• Working Voltage: 5V
• Working Current: 5mA
• Interface: SPI

Connectivity:

This CAN Bus module does not require a logic-level filter because it features built-in level-shifting circuitry. This circuitry supports both 3.3V and 5V logic levels, ensuring compatibility with controllers like the ESP32 or Arduino. Employing a simple SPI (Serial Peripheral Interface) interface for communication with microcontrollers, it seamlessly integrates into various projects.

Pinout:

Uses:

• CAN-BUS Communication
• Robotic control

Documentation:

• Arduino IDE library.
